Auto Steer for John Deere Tractors

Serving the United States

Created by Farmers for Farmers

Buy-Back Guarantee

Two-Year Warranty

Precision Products for New and Older Equipment

From a 4440 to an 8R, steer ready or not
From a 4440 to an 8R, steer ready or not

FJD Auto Steer Systems

We sell, ship and support auto steer in every state. This page is about John Deere tractors. Different brand? The FJD auto steer systems page covers them all, or just call us.

John Deere auto steer kits for any model, any year

A John Deere auto steer kit from Deep Sand Tech is an FJDynamics system that goes on the Deere you already own. If the tractor has power steering and nothing else, an electric steering motor bolts to the column and turns the wheel. If it was guidance-ready from the factory, the kit plugs into the steering valve that is already there. Either way you get a display in the cab, a receiver on the roof and pass-to-pass accuracy of about one inch with RTK.

Deep Sand Tech puts affordable FJDynamics auto steer on John Deere tractors of every age, from a 4020 or 4440 with the original seat to a new 8R, steer ready or not. If it has a steering wheel and power steering, Deep Sand Tech has you covered! Every system comes with sub-inch RTK accuracy unlocked, a two-year warranty, fast US based phone and remote-login support, and a 1-year buy back guarantee.

Get a quote for your Deere Call or Text (580) 394-0089
Any Deere1970s two-wheel drives, articulated 9000s, R-series, combines and sprayers
Within 1 inchRTK pass-to-pass accuracy on the same lines year after year
Keep your valveGuidance-ready Deeres plug in. Nothing from the factory gets replaced
1-year buy backRun it a season. If it is not for you, we buy it back

On this page: model list · older John Deeres · three ways we steer a Deere · what comes in the kit · questions


John Deere model families and what fits

What each family came with from the factory, and what we usually put on it. A family being listed means the option existed, not that every tractor has it, so we confirm on your unit before anything ships.

Model familyFrom the factoryWhat we usually install
30, 40, 50, 55 and 60 series
4040, 4240, 4440, 4640, 4840, 4050, 4250, 4450, 4650, 4850, 4055, 4255, 4455, 4555, 4755, 4955, 4560, 4760, 4960
No steering valve. Power steering only.Electric motor kit on the column. These are the tractors we put the most kits on.
5E and 5M
5045E to 5100E, 5065M to 5115M
No steering valve.Electric motor kit.
5R
5090R, 5100R, 5115R, 5125R
Guidance-ready units have a hydraulic steering valve.AH2 hydraulic kit if the valve is there, otherwise the motor kit.
6000 series
6100 to 6930, including 6420, 6620, 6330, 6430
Premium guidance-ready units have a valve. Standard-cab units usually do not.We check your unit. AH2 on the valve, motor kit on everything else.
6M and 6J
6105M to 6195M, 6145J to 6210J
Guidance-ready option had a valve, base models did not.AH2 if the valve is there, otherwise the motor kit.
6R
6105R to 6250R, 6R110 to 6R250
Steers over Deere’s CAN network from the factory.Electric motor kit. Ask us about AH2 wired to the steering valve.
7000 series
7200 to 7810, 7720 to 7930, 7130 to 7630
Base models have no valve. Later guidance-ready 7020 and 7030 units do.Motor kit on the 7200 to 7810. We check the 7020 and 7030 series for a valve first.
7R
7200R to 7310R, 7R210 to 7R350
Steers over Deere’s CAN network.Electric motor kit. Ask us about AH2 wired to the steering valve.
8000, 8010, 8020 and 8030 series
8100 to 8530, including 8410, 8420, 8320, 8330
Base 8000 and 8010 have no valve. Guidance-ready 8020 and 8030 units carry one over the rear axle.AH2 plugs into that valve with the Deere hydraulic harness. No valve, motor kit or AH2 with a valve added.
8R, 8RX and 8RT
8225R to 8400R, 8R230 to 8R410, 8RX, 8RT
CAN network. The 2010 model year 8R came with a hydraulic valve instead.Electric motor kit, or AH2 wired to the valve. The 8310RT and 8335R are both running our hydraulic kit today.
9000, 9020 and 9030 articulated
9100 to 9620, 9230 to 9630, 8560 to 8970
Base models have no valve. Guidance-ready 9020 and 9030 units do.Motor kit runs these well in articulated mode. AH2 on the valve where there is one.
9R, 9RX and 9RT
9360R to 9620R, 9R390 to 9R640, 9RX, 9RT
CAN network.Electric motor kit, run in articulated mode.
Track tractors
8000T to 8030T, 9000T to 9030T
No valve.Electric motor kit or AH2 with a valve added.
Combines
9560 to 9870 STS, S550 to S790
Guidance-ready units have a hydraulic valve.AH2 on the valve. The motor kit also works, a 9660 STS runs one.
Self-propelled sprayers
4700 to 4940, R4023 to R4045, 408R to 616R
Guidance-ready units have a valve. Three different valve setups by model year.AH2. Send us a photo of the valve and we match the harness before it ships.

Looking for one model number? The John Deere steer-ready model list has every family that ever had a factory guidance option, line by line, with the kit we install on each.

Not on the list, or a different brand wearing the same model number? Call us. We have put kits on 1983 4640s and on 8360Rs.


Auto steer for older John Deere tractors

The older Deeres are the tractors we put the most kits on. The 4020, the 4030 through 4630, the 4040 through 4840, the 50, 55 and 60 series and the 8560 through 8970 four-wheel drives came with power steering and no steering valve. They take the electric steering motor kit on the column.

  • What the tractor needs. A steering wheel, power steering, 12 volts and a place on the roof for the receiver. The kit does not talk to the tractor, so a Deere with no electronics at all runs it.
  • Same accuracy as a new tractor. Accuracy comes from the RTK correction and the receiver, not the tractor. With RTK the kit holds about one inch pass to pass on a 4440 the same as on an 8R.
  • Tighten the front end first. Worn tie-rod ends, worn ball joints and loose U-bolts show up as a tractor that hunts back and forth. The auto steer for older tractors guide has a ten-minute steering check.
  • Look for an old dealer system. If a dealer put guidance on the tractor years ago, the steering valve and the harness near the column usually stayed when the display left. That tractor can take the AH2 on the valve instead of the motor.
  • It moves with you. The kit moves to your next tractor when this one goes down the road, whatever brand that is.

Want to see one working? A customer sent us video from the cab of his nearly 50 year old two-wheel-drive John Deere, planting over terraces with the auto steer driving. It is on the older tractors page.


Three ways we steer a Deere

  1. Electric steering motor kit on the column

    AT2 Lite, AT2, AT2 Max or AT2 Ultra. A motor and a model-specific bracket bolt to the steering column and turn the wheel. Fits any Deere with a steering wheel. This is what goes on the 30 through 60 series, the 5000s, most 6000s, 7000s, base-model 8000s and 9000s, and the track tractors. Most farmers install it themselves in an afternoon.

  2. AH2 hydraulic kit on the factory valve

    Deere’s guidance-ready option put a hydraulic steering valve on many 6000, 7000, 8000 and 9000 series tractors, STS and S-series combines and the 4-series sprayers. AH2 plugs into that valve. We do not replace it. If your Deere has no valve, we can add one. Any tractor with power steering can run a hydraulic kit.

  3. Newer R-series

    6R, 7R, 8R, 8RX, 8RT, 9R, 9RX and 9RT steer over Deere’s CAN network from the factory, and Deere does not open that network to other brands. On these we run the electric motor kit, or wire the AH2 to the steering valve. Both are working in the field today. We tell you which after we see the model and year.


What comes in a John Deere auto steer kit

The motor kit is self-contained. This is what shows up at the farm.

  • Steering motor. A motorized steering wheel that takes the place of yours on the column, with the bracket and spline adapter matched to your Deere from a photo.
  • Receiver. The GNSS receiver goes on the cab roof and takes the RTK correction over cellular or radio.
  • Display. A 10-inch tablet on the AT2 Lite, a 10-inch display on the AT2 or a 12-inch display on the AT2 Max. It mounts where you want it in the cab.
  • Power lead. One 12-volt lead to the battery.
  • RTK. Every kit ships with an RTK plan and sub-inch RTK accuracy unlocked. Most customers run on the GEODNET network, with no base station of their own.
  • Backing. A two-year warranty, a 1-year buy back guarantee, and US based phone and remote-login support.

On a guidance-ready Deere the AH2 kit leaves your steering wheel stock. It plugs into the factory steering valve instead of putting a motor on the column.


See the AT2 motor kit

The same kit that goes on a Deere. One minute and eighteen seconds.

Deep Sand Technology's AT2 Autosteering System by Fjdynamics

What goes on the tractor

FJD AT2 electric steering motor mounted on a tractor steering column
The motor bolts to the steering column and turns the wheel. Nothing in the hydraulics is touched.
FJD GNSS receiver mounted on a tractor roof
The GNSS receiver goes on the roof and takes the RTK correction over cellular or radio.

Things we have learned on Deere installs

  • Deere steering columns take FJD’s column bracket with U-bolts. On a 4055 it is the U-bolt style, not the block style. On an older 4640, check that all six bolts bite the spline before you call it done.
  • On a 6330 Premium the hazard switch sits where the motor wants to be. Move the switch or run a spline extension.
  • On the 8000 series, look over the rear axle for a valve block with three plugs. The round shiny part next to it is a flow meter, the black one is the valve. If the valves are not over the axle, the tractor needs a different Deere cable that plugs straight into the valve.
  • If a Deere or Trimble dealer installed guidance on your tractor before you bought it, the valve and the wiring harness near the column are usually still there even though the display and globe went with the old owner. That tractor is an AH2 plug-in.
  • Deere’s 8 series and 9 series use different CAN systems. What works on one does not carry over to the other.
  • On a 9300 articulated tractor with a wheel angle sensor, we run the display in articulated mode with the attitude sensor set to middle and control model 3. That is the setup that holds a line on terraces.
  • Steering slop is the enemy. Loose U-bolts, worn tie-rod ends and ball joints show up as a tractor that hunts back and forth. We tighten the iron before we tune the software.
What to send us for a quote
  • Model and year, and whether it is two-wheel drive, MFWD, articulated or tracks.
  • A photo of the steering column from the seat, so we match the bracket and spline.
  • On 8000 series and up, a photo over the rear axle so we can see whether the valve block is there.
  • Any implement you want rate or section control on, with the controller’s part number if you can read it.
Talk to farm experts

Common questions from Deere owners

What auto steer kit fits a John Deere tractor?

Deep Sand Tech sells FJDynamics auto steer kits for John Deere tractors of any age. A Deere with power steering and no factory guidance takes the electric steering motor kit on the column. A Deere that was guidance-ready from the factory takes the AH2, which plugs into the steering valve already on the tractor. Send us the model and year and we tell you which one.

What is the best auto steer for an older John Deere?

For a Deere with power steering and no factory guidance, the electric steering motor kit. It bolts to the steering column, runs off the battery and does not touch the hydraulics. The AT2 Lite is the simple start, the AT2 adds implement control and automatic U-turns, and the AT2 Max adds the bigger display. If the tractor still has a steering valve from an old dealer system, the AH2 uses that valve instead.

How accurate is auto steer on a John Deere with an FJD kit?

With RTK the FJD kits hold pass-to-pass accuracy of about one inch (2.5 cm). Accuracy comes from the RTK correction and the receiver, not the tractor, so an older 4440 holds the same line a new 8R does.

Can I move the kit from my John Deere to another tractor?

Yes. The motor kit is not tied to one tractor or one brand. You can buy the extra parts to make your own swap kit, so one system moves between a planting tractor and a spraying tractor, and it goes with you when a tractor goes down the road.

Will auto steer work on my 1979 John Deere 4440?

Yes. The electric motor kit bolts to the steering column and turns the wheel, so it works on any Deere with a steering wheel and power steering. The 4040 through 4960 are the tractors we put the most kits on.

My Deere was guidance-ready from the factory but I never bought the Deere system. Do I have to?

No. Guidance-ready Deeres already have the hydraulic steering valve in them. Our AH2 kit plugs into that valve and steers the tractor with our display and receiver. Nothing from Deere is needed to make it work.

Do I have to replace my steering valve?

No. If the valve is there we use it. On an 8310RT, for example, the kit plugs straight into the existing valve. If your tractor has no valve, you can either run the motor kit or have us add a valve for the AH2.

Can it steer a newer 8R, 7R or 6R?

Yes. Those tractors steer over Deere’s CAN network, and Deere does not open that network to other brands, so we either run the electric motor kit or wire the AH2 to the steering valve. Both are in the field today. Tell us the model and year and we will tell you which one.

Will it run my Deere planter or rate controller?

Steering, yes, on any tractor. Rate and section control depends on the implement. A lot of Deere planters and rate controllers have a plug that looks like ISOBUS but runs Deere’s own protocol, so we check the controller’s part number before promising rate control.

Do I need my own base station?

Usually not. Every kit ships with an RTK plan, and most customers run on the GEODNET network, which needs no base station of your own. Where coverage is thin we set you up with a base station or StarNav. We check coverage at your farm before we quote.

Who installs it and who do I call?

Most farmers install the motor kit themselves in an afternoon with our tech on the phone. Hydraulic kits take longer and we walk you through it or point you to an installer. After that you call or text Deep Sand Tech, and we can log into the display remotely to help.

Can I put auto steer on a John Deere 7200R?

Yes. The 7R tractors (7200R to 7280R, and the later 7210R to 7310R) were sold with a factory guidance-ready option that steers over CAN. FJD's CAN tie-in on Deere is case by case and needs the Deere ECU and a special cable, so the AT2 electric steering motor kit on the column is the sure fit and what most 7R owners run. Send the serial and whether the tractor has the factory guidance activation and we tell you which way to go.

What about a 6105R, or an older 6420?

A 6105R is the same story as the 7R: guidance-ready over CAN from the factory, motor kit is the sure fit, CAN tie-in case by case. A 6420 from the 6020 series is different: the guidance-ready ones carry a FEMA proportional valve that the AH2 drives directly, and the standard-cab tractors without it take the motor kit. Look for the valve block over the rear axle.

My 8410 was never guidance-ready. Can it still have auto steer?

Yes. The 8010 series did not come steer-ready from the factory, but a lot of them had the guidance valve added later. Look over the rear axle: a valve block with three plugs means the AH2 drives it with the Deere hydraulic harness. No block means the motor kit on the wheel, or the AH2 with a valve we add. The round shiny part on the block is the flow meter, not the valve; the black one is the valve.

Does auto steer go on a 9650 STS combine?

Yes. The 50-series STS came before the factory guidance option, so a 9650 STS takes the motor kit on the wheel. The 9x60 and 9x70 STS that were ordered guidance-ready carry a FEMA valve the AH2 drives, and the ones that were not take the motor kit the same as the 9650.
